Name: Nickel Metal Anode Ink
SKU: 231001
Price: 325.00 USD
Availability: InStock

E-commerce has transformed the way businesses operate, and having an online store is crucial. Many website builders provide integrated e-commerce solutions, simplifying the process of setting up an online store. Check out this related article to discover the best tools for your needs.

Description

Our nickel ink is an excellent contact paste for SOFC testing, and is especially good for enhancing the electrical contact on the anode side of a cell during fuel cell testing. The nickel ink can also be used as a reference electrode, but any electrical testing with the nickel paste will require that the sample be under a reducing gas to maintain good electrical conductivity.

This is a great ink for making electrical connections for electrochemical testing of fuel cells, ceramic substrates, electrochemical materials, and metals.

Stirring the ink before use is highly recommended. For best results, the ink should be stirred with a spatula or a sonic wand to achieve an even consistency prior to use.

This ink can be used for screen printing for generating electrical connections for wire attachments.

Ask a Question

Name(Required)

First name Last name

Email(Required)

Company(Required)

Your Question

Ask a Question

Tips for Making Electrical Connections

Ensuring a solid connection between your electrodes and current collector is critical for obtaining good test results. Leveraging our experience in electrochemical testing, testing we have we offer the following suggestions for obtaining optimum results with our silver paste product.

Step 1

Cut or punch the metal mesh to the size/geometry that you want to test on your sample.

Step 2

Cut the contact wire to the desired length, with a loop around the perimeter of the mesh with the wire extending past the sample. Place cut mesh in the center of your sample & the looped wire on top of wire mesh.

Step 3

Apply the contact paste around the perimeter of the wire loop, apply a few drops across the mesh for best adhesion strength.

Step 4

Cut and place a straight piece of wire next to the mesh on the sample. Again, cover with ink for adhesion. This will allow for 4 point conductivity testing and a lead for measuring voltage, while the other draws the current.
